Beauty is the sum

What the parts must equal

A renderer that produces AOVs — arbitrary output variables — writes the beauty pass and its constituent passes simultaneously, from the same rays. The light landing on a surface is partitioned: some bounces diffusely, some reflects specularly, some transmits through the material. Stack the diffuse, specular, transmission, emission and any volume contributions back together, and you should recover the beauty exactly. If you do not, something is either misconfigured or quietly clamped somewhere it should not be.

The check is worth doing. Comp the passes in additive mode, set the result to difference against the beauty, and the frame should go black. Any residual luminance is a discrepancy — a pass that went missing, a double-counted contribution, or an AOV that was written with a different filter applied. Finding that residual before the shot reaches finishing is considerably cheaper than finding it after.

The split also has a geometry. Diffuse colour is often separated into direct and indirect — direct being the first-bounce illumination from lights, indirect being everything that arrived after at least one prior reflection or scattering event. The same split applies to specular. Taking a frame apart covers what each pass actually holds and how that affects what you can safely do in comp.

Emission and volume passes typically stand alone, because there is no meaningful albedo to separate from the lighting; the material is the light. Self-luminous surfaces go straight into the beauty without a corresponding irradiance term, which is why their pass is added rather than multiplied.

The discipline this imposes is useful even when you never touch a single pass. If the parts sum cleanly, you know the renderer wrote what it claimed to write. If a denoiser was run per-pass rather than on the beauty, the sum will not close — denoising is nonlinear, and partitioning then denoising then recombining introduces residuals that are neither noise nor detail. The beauty pass, denoised as a whole, remains the reference. Everything else is a controlled deviation from it.
